Standard Widths (16 options)
Popular Sizes
| Part # | Width (in.) | Length (yds) | Rolls/Case | Price/Roll | Add to Shopping List |
|---|---|---|---|---|---|
| VHTC1-sample | Sample | 3 | 1 | $0.00 | |
| VHTC1-0250 | 0.250 | 60 | 144 | $2.15 | |
| VHTC1-0312 | 0.312 | 60 | 96 | $2.23 | |
| VHTC1-0375 | 0.375 | 60 | 96 | $2.69 | |
| VHTC1-0437 | 0.437 | 60 | 72 | $3.13 | |
| VHTC1-0500 | 0.500 | 60 | 72 | $3.58 | |
| VHTC1-0625 | 0.625 | 60 | 60 | $4.48 | |
| VHTC1-0750 | 0.750 | 60 | 48 | $5.37 | |
| VHTC1-1000 | 1 | 60 | 36 | $7.16 | |
| VHTC1-1500 | 1.50 | 60 | 24 | $10.74 | |
| VHTC1-2000 | 2 | 60 | 24 | $14.32 | |
| VHTC1-3000 | 3 | 60 | 12 | $21.48 | |
| VHTC1-4000 | 4 | 60 | 8 | $28.64 | |
| VHTC1-5000 | 5 | 60 | 8 | $35.80 | |
| VHTC1-6000 | 6 | 60 | 8 | $42.96 | |
| VHTC1-28000 | 28 | 60 | 1 | $200.48 |
Custom sizes available: Contact us if you do not see the width you need. All tapes are slit to width at time of order and cannot be returned for refund or credit.
Technical Specifications
Physical Properties
Performance
Downloads
Application Tips
Apply Pressure
Clean Surface
Dry Surfaces Only
Cover Large Areas
Single Use
Storage
Warm Removal
Apply Pressure
Push down hard! This is a pressure sensitive adhesive tape — pressure is required for it to adhere properly to parts.
Clean Surface
Clean parts thoroughly before applying tape.
Dry Surfaces Only
Apply tape to dry surfaces only.
Cover Large Areas
Use paper or aluminum foil to cover large surface areas; tape edges down.
Single Use
Tape is for intermittent, one-time use only.
Storage
Store rolls on end in a cool, dry place.
Warm Removal
For optimal results, remove the tape while the part is still warm.
All tapes are slit to width at time of order and cannot be returned for refund or credit.
Need a custom size?
We provide custom slit widths and die cut shapes to your exact specifications.
- Precision slit-to-width tape rolls ship same day
- In stock tools for rectangles, squares, circles and donuts
- Low-cost tooling, fast turnaround time on custom die cuts
- Short run custom die cuts with no tooling on select tapes
- Design Engineer on staff to assist with custom masking needs
Related Products
Series: VHTC1-LINED
PG-21 Tape On Liner
Viadon provides PG-21 masking tape by Intertape on release liner for making die cuts on your in-house plotter/cutter. PG-21 is the industry-standard wet-spray painting mask, that we call our VHTC1 series. Conforms well to irregular and curved surfaces, it is easily hand-tearable. Will withstand temperatures up to 30 minutes at 325°F with clean removal while parts are warm (this is recommended). Available in three widths. With medium tack and good line definition, PG-21 crepe tape is designed with a pressure sensitive adhesive. Apply to fully clean parts, then push down with moderate pressure to achieve best paint lines
Series: VHTCD
PG21 High Temp Crepe Tape Disks
Standard masking dots can bleed or leave adhesive residue after a 325°F bake cycle. Intertape PG-21 high temperature masking tape is die-cut into our VHTCD crepe disks, specifically engineered for industrial wet spray painters who need a reliable, conformable mask that removes cleanly from warm surfaces without flaking or slivering. Resists solvent bleed-through.
Series: VIGC
PG505 Industrial Grade Crepe Tape
Intertape's PG505 industrial grade crepe tape is suitable for low or no-bake painting applications. Solvent-based natural rubber pressure sensitive adhesive enables clean removal from most substrates. Comparable to 3M 234 and 3M 203.
Series: VIGCD
Industrial Grade Crepe Tape Disks
Low in cost, but high in quality, these Intertape PG505 crepe tape 5.8 mil thick disks have a natural-rubber adhesive system designed to withstand low-temperature baking cycles for wet-spray masking applications up to 200°F. Not recommended for outdoor exposure.
