V9020-5 - PTFE Coated Fiberglass Tape with Liner

  • PTFE Coated Fiberglass Tape with Liner

PTFE Coated Fiberglass Tape, -100°F to +500°F

PTFE coated fiberglass tape with high temperature silicone adhesive has good chemical resistance, removes cleanly and is perfect for extreme temperatures (-100°F to +500°F / -73°C to +260°C). Ideal as a heat sealing tape or for high temperature masking. In stock in 5 mil thickness. Also available in 3, 10 and 14 mils thick options (non-stock; larger minimum purchase may apply), with or without a release liner.

Note: Rolls are 36 yards long and can be cut in custom widths upon request.
Viadon slits all tapes in-house! PLEASE Contact Us if you do not see the width of tape you need listed below.

  • Available Widths
    Part Number Width (inches) Length (yards) Rolls / Case Quantity (rolls)
    V9020-5-0500 0.500 36 72 Add to Shopping List
    V9020-5-0750 0.750 36 48 Add to Shopping List
    V9020-5-1000 1.00 36 24 Add to Shopping List
    V9020-5-1500 1.50 36 24 Add to Shopping List
    V9020-5-2000 2.00 36 24 Add to Shopping List
    V9020-5-3000 3.00 36 12 Add to Shopping List

    Viadon slits all tapes in-house. PLEASE Contact Us if you do not see the width of tape you need.

    * All tapes are slit to width at time of order and cannot be returned for refund or credit.
    * Stock items are subject to availability, but are usually available for shipment within 24 hours.

  • Technical Specifications
    • Total Thickness: 0.00725"
    • Substrate thickness: 0.0500"
    • Adhesive thickness: 00.00225"
    • Temperature Range: -100°F to +500°F
    • Typical Uses: Wrap or wind around rollers
    • Color: Tan
    • Tensile strength: 100 lbs / sq. in.
    • Adhesion to steel: 30 oz. / in.
    • Elongation until break: ~3%
    • Material: PTFE-coated woven fiberglass
    • Adhesive: Hi-Temp Silicone
    • Excellent resistance to chemicals.
    • Removes cleanly.



    * All tapes are slit to width at time of order and cannot be returned for refund or credit.
    * Stock items are subject to availability, but are usually available for shipment within 24 hours.

    Contact Us for more information.

  • Helpful Hints
    • Push down — This is a pressure sensitive adhesive tape; applying some pressure helps this tape to adhere properly.
    • Ideally, clean surfaces before applying tape.
    • Apply tape to dry surfaces only.
    • Store rolls on end in a cool, dry place.
